HBPS Energy Storage Converter 15~60kW
HBPS energy storage converter 15~60kW. 3-phase, HV 200-850V, >97% efficiency, multi-unit parallel, fast on/off grid switching.
Reference price: $3,309.00Pre-order
Stock: confirmed by orderFor households, installers, dealers, hotels, villas, and factories.
Battery, inverter, PV panel, and accessory availability is confirmed within 24h by city, quantity, and project configuration.
Garanzia 5 years
Spedizione mondiale
100% Originale
Caratteristiche principali
- Conversion efficiency >97%
- High voltage battery 200-850V, compatible with 280/314Ah cells
- 3-phase 400V, multi-unit parallel support
- Fast on/off grid switching <15ms
- Diesel generator hybrid operation support
- Suitable for villas, factories, islands, and farms
Specifiche tecniche
| 15kW | 25kW | 30kW | 40kW | 50kW | 60kW | |
|---|---|---|---|---|---|---|
| Potenza Nominale | 15kW / 15kVA | 25kW / 25kVA | 30kW / 30kVA | 40kW / 40kVA | 50kW / 50kVA | 60kW / 60kVA |
| Corrente Batteria Max | 85A | 80A | 100A | 120A | 150A | 180A |
| Corrente AC Max | 22A | 36A | 43.5A | 57.7A | 72.1A | 87A |
| Potenza Off-grid | 15kVA | 27.5kVA | 30kVA | 40kVA | 50kVA | 60kVA |
| Ingresso PV | - | - | - | 2 MPPT, max 40kW | 2 MPPT, max 50kW | 2 MPPT, max 60kW |
| Tipo | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) | Energy Storage Converter (PCS) |
| Tensione Batteria | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC | HV 200~850VDC |
| Rete AC | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz | 400V/230V 3-phase, 50/60Hz |
| Efficienza | >97% | >97% | >97% | >97% | >97% | >97% |
| Tempo di Trasferimento | <15ms | <15ms | <15ms | <15ms | <15ms | <15ms |
| Parallelo | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel | Multi-unit parallel |
| Comunicazione | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN | RS485, CAN |
| Temperatura | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C | -30~60°C |
| Raffreddamento | Forced air | Forced air | Forced air | Forced air | Forced air | Forced air |
| Garanzia | 5 years | 5 years | 5 years | 5 years | 5 years | 5 years |
Batterie compatibili
Consulenza gratuita via WhatsApp
Risposta entro 5 minuti
Domande frequenti
Qual è la garanzia per HBPS Energy Storage Converter 15~60kW?▼
HBPS Energy Storage Converter 15~60kW è coperto da una garanzia di 5 years da Batelithium. Forniamo assistenza tecnica completa per tutto il periodo di garanzia.
Spedite a livello internazionale?▼
Batelithium spedisce in tutto il mondo. Spedizione gratuita per ordini all'ingrosso. Contatta il nostro team per un preventivo personalizzato.
